Gauze folding rolling machine is suitable to make automatically for gauze inward 4-ply folding.

Features:
1.In-feed width: 900mm,in-feeding roller core diameter: 76mm
2. The output roll diameter and fold width are as per end-usersa choice.
3.The maximum diameter of raw material:700mm, output roll core spindle diameter: on customera request.
4.Auto folding, precise rolling, easy operation, high speed, stable operation.

Main Data:
Name:Gauze Folding Rolling Machine
Model:PPD-GFRM90
Product number of layers:4layers(2 Folds)
Gauze roll width:max900mm
Gauze roll ID:76mm
Gauze roll OD:max700mm
Product roll width:220mm
Speed:10-150m/min
Power:2.2kw
Voltage:380V, 50Hz, 3PH
